Warne CZ 75 / Shadow 2 +4 Extended Magazine Base Pad

Warne® Handgun Magazine Extensions are available in both increased capacity models, and zero capacity models for 10 round capacity limits. These extensions feature an ergonomic shape that allows for better insertion, and finger grooves, allowing the magazine to be stripped from the handgun if needed.

To install the Warne® Magazine Extension:

1. Remove the factory base pad.
2. Remove the screw and washer from the magazine extension and set aside. If the model of magazine extension you have came with a replacement spring, remove the factory follower from the spring and install it on the new provided spring in the same direction it was on the factory spring.
3. Inspect the inside of the magazine tube for excess material or debris, there must be a smooth transition from the magazine tube to the extension.
4. Insert the spring ensuring that the follower is facing the correct direction.
5. Compress the spring into the magazine tube and while holding the spring below the flange of the magazine with one thumb slide the Warne magazine extension onto the flange at the bottom of the magazine.
6. Slide the magazine extension all the way on until the spring pops into the extension cavity.
7. Install the screw and washer and firmly tighten. The washer will compress as the screw is tightened, so be careful to not overtighten the screw.

WARNING & DISCLAIMER: Not for sale, possession, or use in any jurisdiction where the Warne® Handgun Magazine Extensions would violate applicable law or expand a firearm magazine capacity beyond the applicable limit. It is the responsibility of purchaser and user of the Warne® Handgun Magazine Extensions to know and comply with applicable firearms laws, including magazine capacity limits or modification of firearms. By acquiring Warne® Handgun Magazine Extensions, purchaser represents that Warne® Handgun Magazine Extensions can be lawfully used in purchaser’s state or local jurisdiction. Warne specifically disclaims all liability related to any possession, transfer

(sale, gift, exchange or otherwise), use, or modification of this product that violates or would cause violation of applicable law.

Warne is not responsible for any harm or damage from misuse or modification of this product or from malfunction due to modification of any goods by use of this product contrary to specific Warne provided instructions and specifications.
